 Home >>ProductS & Services>> According to Material >> Iron:
1. Ductile Iron Castings:                                         click to view catalogue
1) molding process: Resin sand/Green Sand
2) Material: EN-GJS-400-15/EN-GJS-500-7/EN-GJS-600-3/EN-GJS-700-2
3) Molding: Hand molding/Molding machine Z145/146/148/Molding line.
4) Possible Heat Treatment: Annealing
5) Industry involved: Municipal industry/Construction industry/ Fluid
industry/Automotive industry
6) Part unit weight range: 0. 5kg-2000kgs
7) Max/Min wall thickness requirements: 4mm-250mm
8) Manufacturer Certification: ISO9001(2000)/ TS16949


2. Grey iron castings:                                                  click to view catalogue
1) molding process: Green sand/Resin sand
2) Material: EN-GJL-150/DIN 1691 GG-15
EN-GJL-200/DIN 1691-GG20
EN-GJL-250/DIN1691-GG25
EN-GJL-300/DIN1691-GG30
3) Molding: Hand molding/ Molding machine Z145/146/148/Molding line.
4) Industry involved: Municipal industry/Construction industry/ Fluid industry/Automotive industry
5) Part unit weight range: 0.5kg-2000kgs
6) Max/Min wall thickness requirements: 4mm
7) Manufacturer Certification: ISO9001(2000)/ TS16949


3. Malleable castings:                                                   click to view catalogue
1) molding process: Green Sand
2) Material: Ferrite Malleable Iron KTH350-10, KTH370-12, KTZ2550-04
3) Molding: Hand-molding/Mechanical molding/Molding machine/Molding line.
4) Possible Heat treatment: Annealing, Normalizing, Quenching
5) Industry involved: Power Transmission/Construction Industry
6) Part unit weight range: 0.2kg-15kgs
7) Max/Min wall thickness requirements: 4mm-10mm
8) Representative Product: Insulator Caps/Fastener/Scaffold
9) Manufacturer Certification: ISO9001(2000)

4.A.D.I. Castings
1) Material: 1000-2,1000-5/1200-1,1200-2
2) Molding: Hand-molding/Mechanical molding/Molding machine/Molding line.
3) Industry involved: truck industry
4) Representative Product: 0.5kg-2000kgs
5) Manufacturer Certification: ISO9001 (2000)
